1CH Dry Contact WiFi Relay Switch Module,DC 12/24V AC 100-240V,Tuya Smart Life app,Compatible with Alexa,Google Home
Product Information
About this item
- Smart WiFi Relay Switch with Dual Control: Tuya Smart Life app Wi-Fi enabled smart relay switch with 1 channel, with extra bluetooth remote function. The device is equipped with potential-free outputs (dry contacts), providing high flexibility in voltage support and various applications. It can be used to control a wide range of home appliances, electrical circuits, and home appliance individually
- APP Remote Control with Multiple Modes: Automate most electrical appliances including Door Access Control System, Electric Outdoor Gate, Sliding Gate Opener, Garage Door Opener, computer and irrigation system. With 2 working modes: self-locking (on/off) and inching (emulate momentary) mode. You can now automate and control remotely every electrical appliance
- Voice Control Compatibility: This WiFi switch can be used with Alexa, Google Assistant, and Siri by creating tap to run on tuya app, and you can use voice control to turn on/off home appliances when busy
- Advanced Timing Function: Set the single/loop/timer and countdown/sunrise schedules to automatically turn on/off your device according to your preferences for easy control
- Compact Design with DIN Rail Mount: Tiny and powerful design can be hidden in your appliance box, and with DIN Rail Mount, fits for your smart home project. Set relay status on tuya app, if used for smart garage door opener, set it to be off, when you experience power failure, it will not open the door
- Flexible Power Supply Options: Supports DC 12/24V and AC 100-240V power input, providing versatile installation options for various electrical systems and applications in homes, farms, factories, offices, and laboratories
Product Description
Setup:Download the “Smart Life” app from the App Store (for iOS) or Google Play (for Android).it support 2.4G wifi only,when pairing,your phone have to connect to the same 2.4G wifi,and make sure to put it close to your router.enable your phone bluetooth also Turn off the power before installation. When the device is powered on for the first time, it will automatically enter pairing mode (the LED indicator will flash quickly).If it doesn’t, press and hold the pairing button for 3–7 seconds until the LED starts flashing rapidly. The app will automatically search for and connect to the device. Enter your correct password,it will be configured Power Supply:110-220v Function:This is a dry contact relay switch — it does not output any voltage on the control side. You can connect the output (control circuit) to either: DC 0–30V, , or AC 90–250V,if output appliance is heavy power,please connect it to an actuator firstly The relay can be wired as: NO & COM for normally open operation, or NC & COM for normally closed operation. Quick to Access 2 Working Modes default Self-lock mode: Works like a wireless switch — press once to turn ON and stay on, press again to turn OFF. Inching mode: works as pluse button.Turns ON when activated, then automatically turns OFF after the set time (1–3600 seconds)Self-lock mode: Works like a regular switch — press once to turn ON and stay on, press again to turn OFF.once configure it with tuya app.set inching from timer Function and Usage Timer switch, setting your schedule Voice control from Alexa or google home and so on Family share Linked with other WIFI sensors to creat smart scence ,go to smart home life Work as a toggle switch or a button This products can be used in homes, farms, factories, offices, laboratories, supermarkets, etc .Wireless remote control applications range from simple household remote controls to automation such as any device start button, computer start button, garage door opener button, door control system button, lights, ventilation device, fan, Lamp, wireless door alarm, monitor, printer, and other electrical equipment etc. It can work as a button or a switch, controlled via WIFI. package:include 1pcs tuya wifi relay module,1pcs instruction
