Goodman 2 Ton 14.5 SEER2 96% AFUE 60,000 BTU Low NOx R-32 Air Conditioner & Gas Furnace System (GLXS4MA2410, CAPTA3022B3, GR9T960603BN)

Product Information

About

Complete Matched Equipment Package: Includes the GLXS4MA2410 R-32 air conditioner condenser, CAPTA3022B3 cased evaporator coil, and GR9T960603BN gas furnace. The 2-ton and 14.5 SEER2 cooling rating applies to the complete matched combination under AHRI certificate 214859245, not to any component by itself; 96% AFUE and 60,000 BTU describe the included furnace.
Outdoor Cooling Equipment: The GLXS4MA2410 is an R-32 single-stage air conditioner condenser for cooling-only operation. Its compressor operates at full output whenever the thermostat calls for cooling, providing the capacity profile specified for this matched system.
Matched Indoor Coil: The CAPTA3022B3 is an R-32 cased upflow/downflow evaporator coil with a factory-installed TXV that adjusts refrigerant flow as operating conditions change. Its all-aluminum coil construction is designed for heat transfer and corrosion resistance, while the cabinet orientation helps align the coil with the selected furnace or blower.
Gas Heating, Airflow, and Emissions: The GR9T960603BN provides 60,000 BTU/h input at 96% AFUE with two-stage heating and a multi-speed ECM blower. Due to local regulations, this furnace is not for sale in Colorado or the special emissions regulation districts of California.
Installation, Warranty, and Exclusions: Professional sizing and installation are required. Verify ductwork, line set/charge, electrical and gas service, venting, combustion air, condensate, controls, clearances, and R-32/local-code compliance. Included equipment is eligible for a 10-year parts limited warranty with timely online registration where required; terms and location exceptions apply. Labor, thermostat, line set, and field accessories are not included.
