waveshare Mini-Computer Based on Raspberry Pi Compute Module 4 (NOT Included), CM4-IO-BASE-A (Lite Ver.) Inside, Metal Case, with Cooling Fan, USB HDMI Adapter, FFC Cables, USB-A to USB-C Cable etc.
Product Information
About this item
- 【Mini-Computer Based on Raspberry Pi CM4】Mini-Computer based on Raspberry Pi Compute Module 4, Waveshare Mini IO Board (Lite Ver.) inside, make it easy to build your own Raspberry Pi CM4 Mini PC
- 【Waveshare Mini IO Board (Lite Ver.) 】CM4-IO-BASE-A designed for Raspberry Pi Compute Module 4, onboard multiple connectors including: CSI/DSI/FAN/HDMI/USB/RJ45 Gigabit Ethernet/Micro SD Card Slot/M.2 Slot, compared with CM4-IO-BASE-B (Full Ver.), there're NO RTC, Fan controller, and battery holder on version A
- 【USB HDMI Adapter】USB HDMI Adapter specialized for CM4-IO-BASE, USB 2.0 to HDMI converter with 2×USB 2.0 Ports, 1×HDMI Ports, 1×USB 2.0 FFC Connector, 1×HDMI FFC Connector, adapting FFC connector to standard connector
- 【Cooling Fan Included】Comes with cooling fan, combined with the airflow vent, better heat dissipation
- 【Precise Cut-Out With Clear Label】Each cut-out is completely aligned with the connector
