ZTBH Microscope Accessories Kit 48MP 4K 2K 1080P 60FPS HDMI USB Electronic Digital Video Microscope Camera 200X C Mount Lens for Lab Phone PCB Solderin Microscope Slides
Product Information
About
Model Number: 48MP USB HDMI Microscope Camera.
10X-200X C-mount Lens: Working distance: 90MM-97MM; zoom ratios: 1 : 7.2; Magnification Power by 0.7- 5X (about 10 - 200X on the display).
view field of Max multiple : 2.8mm*1.6mm; view field of Min multiple : 19mm*11mm; Eyepiece lense : 0.4X; Size: 55mm(diameter) * 132mm(length).
Professional and practical design with beautiful appearance, easy to carry and use.
Usually used in laboratories, schools, teachers, sample observation, eyepiece protection, etc.
Product Description
Function:Picture Pixel:48MTF Card: Video RecorderGrid line:8 horizontal lines, 8 vertical linesVideo Frame Rate: 24FPS@4K(4:3) 24FPS@2K 60FPS@1920x1080 60FPS@720PTF card:4GB (Up to 32GB max)CMOS censer:1/2.33 inchCross line:Overlap or CancelCMOS pixel:1.33um x 1.33umLens jack:C-mountColor setting:AutoPower:12V/1AWhite balance:Auto/one button calibration/ManualSize:68x68x35mmEV:Auto/ManualWeight:180gLanguage:Chinese, EnglishCamera mode:HDMI output 1080P @60 FPSWorking temperature:0-70℃10X-200X C-mount Lens:Working distance: 90MM-97MMzoom ratios: 1 : 7.2Magnification Power by 0.7- 5X (about 10 - 200X on the display)view field of Max multiple : 2.8mm*1.6mmview field of Min multiple : 19mm*11mmEyepiece lense : 0.4XSize: 55mm(diameter) * 132mm(length)Weight: 455g144 bright white LED bulbs 100,000 hours of life Intense and focused shadow-free illumination The brightness of 0-100%Adjustable,high brightness Variable intensity control Power input: 100-240V, 50-60HZ Suit for the dia of the lens: 30mm-160mm Package incluede:1 x FHD Zoom C-mount Lens1 x Microscope Camera1 x Power Adapter1 x remoter1 x USB Lines1 x HDMI Lines1 x C-MOUNT Lens1 x 144 LED Adjustable Microscope Ring Light1 x Holder standNote:1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.2. Please allow slight manual measurement deviation for the data.
